Ausführung - 16

Artnr: 70870617

• A = 250 mm
• B = 120 mm
• C = 6,2 mm

• D = 6,2 mm

• E = M6

• F = -
• G = 21 mm

• H = -
• I = 10 mm
• J = 22 mm

• K = -
• L = -
• J = 22 mm
• Kraft (Newton) = 210 Nm
• Ø Stange = 8 mm

• Ø Gehäuse = 18 mm

Artnr: 70870618

• A = 285 mm
• B = 140 mm
• C = 10,2 mm

• D = 10,2 mm

• E = M6

• F = -
• G = 21 mm

• H = -
• I = 10 mm
• J = 22 mm

• K = -
• L = -
• J = 22 mm
• Kraft (Newton) = 520 Nm
• Ø Stange = 8 mm

• Ø Gehäuse = 18 mm

Artnr: 70870619

• A = 315 mm
• B = 160 mm
• C = 8,2 mm

• D = 8,2 mm

• E = M6

• F = -
• G = 20 mm

• H = -
• I = 10 mm
• J = 22 mm

• K = -
• L = -
• J = 22 mm
• Kraft (Newton) = 520 Nm
• Ø Stange = 8 mm

• Ø Gehäuse = 18 mm

Artnr: 70870620

• A = 500 mm
• B = 265 mm
• C = 8,2 mm

• D = 8,2 mm

• E = 8 mm

• F = -
• G = 22 mm

• H = 17 mm
• I = 10 mm
• J = 14 mm

• K = 20 mm
• L = 10 mm
• J = 22 mm
• Kraft (Newton) = 960 Nm
• Ø Stange = 10 mm

• Ø Gehäuse = 20 mm

Artnr: 70870646

• A = 885 mm
• B = 445 mm
• C = 8,2 mm

• D = 8,2 mm

• E = M6
• F = -
• G = 19 mm

• H = -
• I = 12 mm
• J = 19 mm

• K = -
• L = -
• J = 19 mm
• Kraft (Newton) = 600 Nm
• Ø Stange = 10 mm

• Ø Gehäuse = 21 mm

Artnr: 70870647

• A = 890mm
• B = 410mm
• C = 8,10mm

• D = 8,10mm

• E = M8
• F = -
• G = 18mm

• H = -
• I = 12mm
• J = 19mm

• K = -
• L = -
• Kraft (Newton) = 800 Nm
• Ø Stange / Rohr = 21mm / 28mm
